Rapiroに赤外線の受信機を搭載してみた

#!/usr/bin/env python

import time
import os
import json
import subprocess

import RPi.GPIO as GPIO
import pigpio

IR_RX_PIN  = 17
GLITCH     = 100
PRE_MS     = 200
POST_MS    = 15
FREQ       = 38.0
SHORT      = 10
TOLERANCE  = 15

POST_US    = POST_MS * 1000
PRE_US     = PRE_MS  * 1000
TOLER_MIN =  (100 - TOLERANCE) / 100.0
TOLER_MAX =  (100 + TOLERANCE) / 100.0

last_tick = 0
in_code = False
code = []
fetching_code = False

def normalise(c):
    entries = len(c)
    p = [0]*entries # Set all entries not processed.
    for i in range(entries):
        if not p[i]: # Not processed?
            v = c[i]
            tot = v
            similar = 1.0

            # Find all pulses with similar lengths to the start pulse.
            for j in range(i+2, entries, 2):
                if not p[j]: # Unprocessed.
                    if (c[j]*TOLER_MIN) < v < (c[j]*TOLER_MAX): # Similar.
                        tot = tot + c[j]
                        similar += 1.0

            # Calculate the average pulse length.
            newv = round(tot / similar, 2)
            c[i] = newv

            # Set all similar pulses to the average value.
            for j in range(i+2, entries, 2):
                if not p[j]: # Unprocessed.
                    if (c[j]*TOLER_MIN) < v < (c[j]*TOLER_MAX): # Similar.
                        c[j] = newv
                        p[j] = 1

def compare(p1, p2):
    if len(p1) != len(p2):
        return False

    for i in range(len(p1)):
        v = p1[i] / p2[i]
        if (v < TOLER_MIN) or (v > TOLER_MAX):
            return False

    for i in range(len(p1)):
        p1[i] = int(round((p1[i]+p2[i])/2.0))

    return True


def end_of_code():
    global code, fetching_code
    if len(code) > SHORT:
        normalise(code)
        fetching_code = False
    else:
        code = []
        print("Short code, probably a repeat, try again")

def cbf(gpio, level, tick):
    global last_tick, in_code, code, fetching_code

    if level != pigpio.TIMEOUT:

        edge = pigpio.tickDiff(last_tick, tick)
        last_tick = tick

        if fetching_code:

            if (edge > PRE_US) and (not in_code): # Start of a code.
                in_code = True
                pi.set_watchdog(IR_RX_PIN, POST_MS) # Start watchdog.

            elif (edge > POST_US) and in_code: # End of a code.
                in_code = False
                pi.set_watchdog(IR_RX_PIN, 0) # Cancel watchdog.
                end_of_code()

            elif in_code:
                code.append(edge)

    else:
        pi.set_watchdog(IR_RX_PIN, 0) # Cancel watchdog.
        if in_code:
            in_code = False
            end_of_code()

pi = pigpio.pi() # Connect to Pi.

if not pi.connected:
    exit(0)

with open('/[homeディレクトリ]/switchbot') as f:
    key_config = json.load(f)

    pi.set_mode(IR_RX_PIN, pigpio.INPUT) # IR RX connected to this IR_RX_PIN.

    pi.set_glitch_filter(IR_RX_PIN, GLITCH) # Ignore glitches.

    cb = pi.callback(IR_RX_PIN, pigpio.EITHER_EDGE, cbf)

    try:
        while True:
            code = []
            fetching_code = True
            while fetching_code:
                time.sleep(0.1)
            time.sleep(0.5)
            key_name = "-"
            for key, val in key_config.items():
                if compare(val, code[:]):
                    key_name = key
            if key_name == "interphone":
                subprocess.call("aplay /[homeディレクトリ]/wav/interphone.wav", shell=True)

    except KeyboardInterrupt:
        pass
    finally:
        pi.stop() # Disconnect from Pi.
